WE DELIVER PROPOSALS AND SERVICES THAT MEET THE NEEDS OF OUR CUSTOMERS' PROCESS.
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | STTOY |
| Model Number: | Alloy cold rolled steel strip |
| Minimum Order Quantity: | 1 ton |
| Packaging Details: | Pallet(required by the customers' requirements) |
| Delivery Time: | 20-60 working day |
| Payment Terms: | L/C,T/T,Paypal |
| Supply Ability: | 100 tons |
| High Light: | galvanised steel strip,cold rolled coil |
||
|---|---|---|---|
1J46, 1J50, 1J54 T: 0.03—0.10mm W:180—250mm T: 0.10—1.0mm W: 10—250mm T: 1.00—2.50mm
Description:
Having a high saturation magnetic induction and a high magnetic permeability.
Applications:
Moderate magnetic field transformer, relay, electromagnetic clutch, choke, and magnetic circuit parts of the core, the pole piece, headset diaphragm, earth leakage circuit breakers, earth leakage circuit breaker relay parts, gas safetyvalve, magnetic shielding, gyro, automatic synchronous motor, electronic table micro-motors.
Specifications:
Thickness:0.03—0.10mm Width:180—250mm
Thickness:0.10—1.0mm Width:10—250mm
Thickness:1.00—2.50mm Width:100—250mm
Tolerance: +/-0.01mm.
Other specifications can be customized
Surface:2B
Hardness:240—280HV(As order’s requirements)
MOQ:1 tons
Port of Loading:Shanghai
Payment:T/T
High permeability DC magnetic properties of high saturation magnetic induction soft magnetic alloy
|
Alloy Name |
Type |
Level |
Thickness /diameter /mm |
The agnetic permeability μ in 0.4A / m magnetic field strength μ0.4 (mH / m) |
Maximum permeability μm (mH / m) |
Coercivity (saturation magnetic induction) Hc/A·m-1 ≤ |
Saturation magnetic induction Bs/T |
|
≥ |
|||||||
|
1J46 |
Cold rolled strip |
|
0.03~0.04 |
1280(1.6) |
18000(22.5) |
32 |
1.5 |
|
0.05~0.09 |
1600(2.0) |
22000(27.5) |
24 |
1.5 |
|||
|
0.10~0.19 |
2000(2.5) |
25040(31.3) |
20 |
1.5 |
|||
|
0.20~0.34 |
2480(3.1) |
30000(37.5) |
16 |
1.5 |
|||
|
0.35~2.50 |
2800(3.5) |
36000(45.0) |
12 |
1.5 |
|||
|
Hot rolled flat |
|
4.5~20 |
2000(2.5) |
25040(31.3) |
16 |
1.5 |
|
|
Hot forging bar |
|
20~100 |
2000(2.5) |
25040(31.3) |
16 |
1.5 |
|
|
1J50 |
Cold rolled strip |
Ⅰ |
0.05~0.09 |
2000(2.5) |
28000(35) |
20 |
1.5 |
|
0.10~0.19 |
2320(2.9) |
32000(40) |
14.4 |
1.5 |
|||
|
0.20~0.34 |
2640(3.3) |
40000(50) |
11.2 |
1.5 |
|||
|
0.35~0.50 |
3040(3.8) |
50000(62.5) |
9.6 |
1.5 |
|||
|
0.51~1.00 |
3040(3.8) |
50000(62.5) |
9.6 |
1.5 |
|||
|
1.10~2.50 |
2800(3.5) |
45040(56.3) |
9.6 |
1.5 |
|||
|
Ⅱ |
0.10~0.19 |
3040(3.8) |
35040(43.8) |
12 |
1.5 |
||
|
0.20~0.34 |
3520(4.4) |
45040(56.3) |
10.4 |
1.5 |
|||
|
0.35~0.50 |
4000(5.0) |
52000(65) |
8.8 |
1.5 |
|||
|
0.51~1.00 |
4000(5.0) |
40000(50) |
10 |
1.5 |
|||
|
1.10~2.50 |
3040(3.8) |
35200(44) |
12 |
1.5 |
|||
|
Ⅲ |
0.05~0.20 |
10000(12.5) |
60000(75) |
4.8 |
1.52 |
||
|
Hot rolled flat |
|
4.5~20 |
2480(3.1) |
25040(31.3) |
14.4 |
1.5 |
|
|
Hot forging bar |
|
20~100 |
2480(3.1) |
25040(31.3) |
14.4 |
1.5 |
|
|
1J54 |
Ⅰ |
|
0.03~0.04 |
1520(1.9) |
16000(20) |
20 |
1.0 |
|
|
0.05~0.09 |
2000(2.5) |
20000(25) |
16 |
1.0 |
||
|
|
0.10~0.19 |
2480(3.1) |
25040(31.3) |
12 |
1.0 |
||
|
|
0.20~0.34 |
3040(3.8) |
28000(35) |
9.6 |
1.0 |
||
|
|
0.35~0.50 |
3200(4.0) |
32000(40) |
8 |
1.0 |
||
|
|
0.51~1.00 |
3040(3.8) |
32000(40) |
8 |
1.0 |
||
|
Ⅱ |
|
0.03~0.04 |
3040(3.8) |
24800(31) |
12 |
1.0 |
|
|
|
0.05~0.09 |
3040(3.8) |
24800(31) |
12 |
1.0 |
||
|
|
0.10~0.19 |
3120(3.9) |
28000(35) |
10 |
1.0 |
||
|
|
0.20~0.34 |
3120(3.9) |
30000(37.5) |
10 |
1.0 |
||
|
|
0.35~0.50 |
3520(4.4) |
35200(44) |
8 |
1.0 |
||
|
Hot rolled flat |
|
4.5~20 |
1600(2.0) |
16000(20) |
20 |
1.0 |
|
|
Hot forging bar |
|
20~100 |
1600(2.0) |
16000(20) |
20 |
1.0 |
|
Competitive Advantage:
First-class quality, complete specifications, reasonable price, timely delivery and rigorous specified according to customer requirements, suited materials for basic principles, to allow customers to buy satisfaction with assured.
