WE DELIVER PROPOSALS AND SERVICES THAT MEET THE NEEDS OF OUR CUSTOMERS' PROCESS.
| Place of Origin: | China |
|---|---|
| Brand Name: | zhuxin |
| Certification: | CE,ISO9000 |
| Price: | Negotiable |
| Packaging Details: | Seaworthy package |
| Delivery Time: | 15-40days |
| Payment Terms: | TT/LC |
| Supply Ability: | 3,500MT/month |
| High Light: | polished stainless steel plate,stainless steel metal plate |
||
|---|---|---|---|
2B Surface mirror finish stainless steel plating SUS JIS EN DIN BS for construction
Quick Detail:
1. Commodity: cold rolled stainless steel sheet
2. Brand: JISCO, LISCO, TISCO
3. Material: 201,202,304,304L,309S,310S,316,316L,316Ti,317L,321,347H,
409,409L,410,420,430
4. Certification: ISO,SGS BV
5. Surface: 2B, or as requested
6. Thickness: 0.5mm-6mm
7. Width: 1000mm/1219mm/1500mm
8. Length: 2000mm,2440mm(8feet),2500mm,3000mm,3048mm(10feet),5800mm,
6000mm or we can make the length as you require
9. Standard: ASTM,AISI,SUS,JIS,EN,DIN,BS,GB
Specifications
Surface Finish
| Name | Feature | Specification |
| 2B | Bright | After coldrolling,by heat treatment,picking or other equivalent treatment and lastly by cold rolling to given appropriate luster |
| 2D | Matte | Best choice for deep drawing |
| BA | POlishing,Mirror |
Processed with bright heat treatment after cold rolling |
| NO4 | Discontinuous coarse grain | Grinding and polishing surface by 150-180# strop grain of abrasive belt |
| Hair Line | Line like hair |
Hair grain grinding by appropriate particle size of material |
| 6K | Mirror,Brighter than BA |
very bright,grinding and polishing surface by 100# strop grain of abrasive belt |
Regular size
| Thickness(mm) | Width(mm) | Length(mm) | Thickness(mm) | Width(mm) | Length(mm) |
| 0.5 | 1219 | 2438 | 1.2 | 1000 | 2000 |
| 0.5 | 1000 | 2000 | 1.5 | 1219 | 2438 |
| 0.6 | 1219 | 2438 | 1.5 | 1000 | 2000 |
| 0.6 | 1000 | 2000 | 2.0 | 1219 | 2438 |
| 0.7 | 1219 | 2438 | 2.0 | 1000 | 2000 |
| 0.7 | 1000 | 2000 | 3.0 | 1219 | 2438 |
| 0.8 | 1219 | 2438 | 3.0 | 1000 | 2000 |
| 0.8 | 1000 | 2000 | 3.0 | 1500 | 6000 |
| 1.0 | 1219 | 2438 | 4.0 | 1500 | 6000 |
| 1.0 | 1000 | 2000 | 5.0 | 1500 | 6000 |
| 1.2 | 1219 | 2438 | 6.0 | 1500 | 6000 |
Technical Requirement
|
TYPE NO. |
C |
Mn |
P |
S |
Si |
Cr |
Ni |
|
|
% |
% |
% |
% |
% |
% |
% |
|
201 |
≤ 0.15 |
5.5-7.5 |
≤ 0.050 |
≤ 0.03 |
≤ 1.00 |
16.0-18.0 |
3.5-5.5 |
|
202 |
≤ 0.15 |
7.5-10 |
≤ 0.060 |
≤ 0.03 |
≤ 1.00 |
17.0-19.0 |
4.0-6.0 |
|
301 |
≤ 0.15 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
16.5-18.0 |
6.0-8.0 |
|
302 |
≤ 0.15 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
17.0-19.0 |
8.0-10.0 |
|
304 |
≤ 0.08 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
18.0-20.0 |
8.0-10.5 |
|
304L |
≤ 0.03 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
18.0-20.0 |
8.0-12.0 |
|
316 |
≤ 0.08 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
16.0-18.0 |
10.0-14.0 |
|
316L |
≤ 0.03 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
16.0-18.0 |
10.0-14.0 |
|
321 |
≤ 0.08 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
17.0-19.0 |
9.0-12.0 |
|
410 |
≤ 0.15 |
≤ 1.00 |
≤ 0.040 |
≤ 0.03 |
≤ 1.00 |
11.5-13.5 |
|
|
430 |
≤ 0.12 |
≤ 1.00 |
≤ 0.040 |
≤ 0.03 |
≤ 1.00 |
16.0-18.0 |
|
Mechanical Properties
|
TYPE NO. |
Y.S |
T.S. |
ELOG. |
hardness |
||
|
|
N/mm2 |
N/mm2 |
% |
HB |
HRB |
HV |
|
301 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 207 |
≤ 95 |
≤ 218 |
|
304 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
304L |
≥ 175 |
≥ 480 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
316 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
316L |
≥ 175 |
≥ 480 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
321 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
410 |
≥ 205 |
≥ 440 |
≥ 20 |
≤ 201 |
≤ 93 |
≤ 210 |
|
430 |
≥ 205 |
≥ 450 |
≥ 22 |
≤ 183 |
≤ 88 |
≤ 200 |
Application
Stainless steel sheet applies to construction field, ships building industry, petroleum &chemical industries,war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and hardware fields. Stainless steel sheet can be made accordingto the customers requirements. Fast delivery. Quality assured.Welcome to order more.
