WE DELIVER PROPOSALS AND SERVICES THAT MEET THE NEEDS OF OUR CUSTOMERS' PROCESS.
| Place of Origin: | China |
|---|---|
| Brand Name: | RISHBIN |
| Certification: | CE |
| Minimum Order Quantity: | 1 Set |
| Price: | Contact Us |
| Packaging Details: | Standard packing |
| Delivery Time: | 100 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 200 Sets Per Year |
| Largest Width:: | 2000mm | Largest Thickness:: | 6mm |
|---|---|---|---|
| Speed: | 0-120m/min | Max Outside Diameter: | 1500mm |
| Max Weight:: | 5 T | Tolerance:: | 0.02mm |
| High Light: | metal slitting machine,steel coil slitting machine |
||
Cold roll steel coil slitting machine
1. Steel thickness: 0.5~3mm
2. Width: 800~1300mm
3. Coil weightaa 15tons
4. Speed: 20m
Popular models for thin material:
| Technical data for RB120 series | ||||||
| model | thickness(mm) | width(mm) | number PCS | Accuracy(mm) | Speed (m/min) |
weight(t) |
| RB120-1*650 | 0.2-1 | 150-650 | 30-8 | ±0.05 | 0-120 | 3,5 |
| RB 120-1*850 | 0.2-1 | 300-850 | 30-8 | ±0.05 | 0-120 | 5,10 |
| RB 120-1*1050 | 0.2-1 | 300-1050 | 30-8 | ±0.05 | 0-120 | 5,10 |
| RB 120-1*1300 | 0.2-1 | 400-1300 | 30-8 | ±0.05 | 0-120 | 10,15 |
| RB 120-2*650 | 0.3-2 | 150-650 | 30-8 | ±0.05 | 0-120 | 3,5 |
| RB 120-2*1300 | 0.3-2 | 400-1300 | 30-8 | ±0.05 | 0-120 | 10,15 |
| RB 120-3*1300 | 0.4-3 | 400-1300 | 30-8 | ±0.05 | 0-120 | 10,15 |
| RB 120-3*1600 | 0.4-3 | 400-1600 | 30-8 | ±0.05 | 0-120 | 15,20 |
| RB 120-3*2000 | 0.4-3 | 500-2000 | 30-6 | ±0.05 | 0-120 | 15,20 |
| RB 120-4*1300 | 0.5-4 | 400-1300 | 30-6 | ±0.05 | 0-120 | 10,15 |
| RB 120-4*1600 | 0.5-4 | 400-1600 | 30-6 | ±0.05 | 0-120 | 15,20 |
| RB 120-4*2000 | 0.5-4 | 500-2000 | 30-6 | ±0.05 | 0-120 | 15,20 |
| RB 120-6*1600 | 0.6-6 | 400-1600 | 30-5 | ±0.08 | 0-120 | 15,20 |
| RB 120-6*2000 | 0.6-6 | 500-2000 | 30-5 | ±0.08 | 0-120 | 15,20 |
Cold roll steel coil slitting machine
The steel coil slitting line can do uncoiling, slitting and recoiling works. slit the steel coil into narrower coils with any needed widths. The whole line mainly includes coil loading car, uncoiler, coil guide, slitting machine, scrap winder, tension unit, recoiler, coil unloading car, hydraulic system and electrical control system, etc. It is mainly applied for processing cold/hot rolled carbon steel, silicon steel,stainless steel, and all the other kinds of metal materials with surface spreading.
Main components
1. coil car
2. decoiler
3. peeler entry table
4. Straightener.
5. Shearing machine
6. loop table
7. coil guide and pinch roll
8. Slitting machine
9. scrap winder (both sides)
10. Loop table
11. separator and tension table
12. Deflector roll and exit threading table
13. Recoiler
14. Over arm separator in the recoiler.
15. Exit coil car for recoiler
16. Hydraulic system
17. pneumatic system
18. electrical control system
