| Place of Origin: | CHINA |
|---|---|
| Brand Name: | STTOY |
| Model Number: | 400 series cold rolld stainless steel coil |
| Minimum Order Quantity: | 1 ton |
| Packaging Details: | Pallet(required by the customers' requirements) |
| Delivery Time: | 20-60 working day |
| Payment Terms: | L/C,T/T,Paypal |
| Supply Ability: | 100 tons |
| High Light: | cold rolled steel coil,steel roll |
||
|---|---|---|---|
SUS410 hardenability martensitic cold rolled Stainless Steel Roll with 1.0-3.0mm thickness
SUS410 cold rolled stainless steel coil with thickness:1.0-3.0mm width: 200-1219mm HV160-400 Surface:2B BA
Description:
SUS410 hardenability martensitic stainless steel, it has high hardness, toughness, good corrosion resistance, thermal strength and performance of cold deformation, shock absorption is also very good. Require high temperature or low temperature tempering, but should avoid tempering between 370-560 ℃.
Applications:
Components used for manufacture of resistance to atmospheric corrosion, water vapor, water and oxidizing acid.
Specifications:
Chemical composition:
|
C |
Si |
Mn |
P |
S |
Cr |
Ni |
Mo |
|
≤0.15 |
≤0.60 |
≤1.00 |
≤0.030 |
≤0.028 |
11.50-14.50 |
3.00 |
0.60 |
Mechanical Properties :
|
(N/mm2) |
(N/mm2) |
EL(%) |
HB |
|
195 |
360 |
22 |
183 |
Thinckness:1.0-3.0mm
Width: 200-1219mm
Hardness: HV160-400
width Tolerance:±0.02mm
surface: good arc edge,bright, no scraping wire
The commom size:
0.1*160mm 0.1*300mm 0.1*140mm
0.06*200mm 0.06*300mm 0.06*400mm
0.2*20mm, 0.2*30mm 0.2*40mm
0.2*2mm 0.2*3mm 0.2*4mm
other sizes as your requirements to produce.
Density:
|
Steel Grade |
Density(g/cm3) |
|
201,202,301,302,303, 304,304L,305,321 |
7.93 |
|
316,316L,316S,347,309S,310,310S |
7.98 |
|
405,410,420 |
7.75 |
|
409,430,434 |
7.7 |
Stainless steel theoretical weight formula:
Weight (kg) = thickness (mm) × width (mm) x length (mm) × density values
Stainless steel gravity:
Chromium stainless take 7.75 ton / M3
Chrome-nickel stainless steel take 7.93 ton / M3
Iron take 7.87 ton / M3
Competitive Advantage:
First-class quality, complete specifications, reasonable price, timely delivery and rigorous specified according to customer requirements, suited materials for basic principles, to allow customers to buy satisfaction with assured.
