WE DELIVER PROPOSALS AND SERVICES THAT MEET THE NEEDS OF OUR CUSTOMERS' PROCESS.
| Place of Origin: | China Main Land |
|---|---|
| Brand Name: | GSC |
| Certification: | ISO9000 CE |
| Model Number: | GSC-FG-SS |
| Minimum Order Quantity: | 500kgs |
| Price: | Depend on drawing |
| Packaging Details: | Exporting package |
| Delivery Time: | Depend on contract |
| Payment Terms: | D/P, L/C, D/A, T/T |
| Supply Ability: | Depend on contract |
| Material: | Stainless Steel, 306, 316 And 316L | Size: | 15mm-500mm |
|---|---|---|---|
| Machining: | CNC Milling, Drilling, Lathe And Boring | Heat Treatment: | Anneal And Quench |
| Inspectioin: | Dimension, Chemical, Strength, UV, X-ray | ||
| High Light: | stainless steel forging,forged auto parts |
||
Features:
1) Grade: ASTM: 201, 202, 204Cu, 301, 302, 303, 304, 304Cu, 304HC, 304L, 304H, 310, 310S, 312, 314, 316, 316L, 316LN, 316Ti, 316LCu, 321, 410, 420, 430, 430L
DIN/EN:1.4301, 1.4306, 1.4307, 1.4310, 1.4401, 1.4404, 1.4567, 1.4841, 1.4842, 1.4541, 1.4845, 1.4570, 1.4571, 1.4578, 1.4597, 1.4362, 1.4370, 1.4016
2) Standard: GB,SUS,ASTM,AISI, EN,DIN,JIS,BS - also to other equivalent international standards.
3) Diameter: 0.016-26mm
4) Surface: bright, cloudy, plain, black
5) Condition: soft wire, semi-soft wire, hard wire
6) Type: Hydrogen, Cold-drawn, Cold heading, Annealed
7) Packing: in coil, bundle or spool then in carton, or as your request
Chemical Composition:
| Composition, % | ASTM A580/A580M - 13b | |||||||||
| UNS-Designation | Type | Carbon | Manganese | Phosphonus | Sulfur | Silicon | Chromium | Nickel | Molybdenum | Nitrogen |
| S30200 | 302 | 0.15 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0–19.0 | 8.0–10.0 | . . . | 0.10 |
| S30215 | 302B | 0.15 | 2.00 | 0.045 | 0.030 | 2.00–3.00 | 17.0–19.0 | 8.0–10.0 | . . . | . . . |
| S30400 | 304 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 18.0–20.0 | 8.0–10.5 | . . . | 0.10 |
| S30403 | 304LC | 0.030 | 2.00 | 0.045 | 0.030 | 1.00 | 18.0–20.0 | 8.0–12.0 | . . . | 0.10 |
| S30500 | 305 | 0.12 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0–19.0 | 10.5–13.0 | . . . | . . . |
| S30800 | 308 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 19.0–21.0 | 10.0–12.0 | . . . | . . . |
| S30900 | 309 | 0.20 | 2.00 | 0.045 | 0.030 | 1.00 | 22.0–24.0 | 12.0–15.0 | . . . | . . . |
| S30908 | 309S | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 22.0–24.0 | 12.0–15.0 | . . . | . . . |
| S30940 | 309Cb | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 22.0–24.0 | 12.0–16.0 | . . . | 0.10 |
| ... | ... | ... | ... | ... | ... | ... | ... | ... | ... | |
| S31000 | 310 | 0.25 | 2.00 | 0.045 | 0.030 | 1.50 | 24.0–26.0 | 19.0–22.0 | . . . | . . . |
| S31008 | 310S | 0.08 | 2.00 | 0.045 | 0.030 | 1.50 | 24.0–26.0 | 19.0–22.0 | ... | ... |
| S31400 | 314 | 0.25 | 2.00 | 0.045 | 0.030 | 1.50–3.00 | 23.0–26.0 | 19.0–22.0 | ||
| S31277 | . . . | 0.020 | 3.00 | 0.030 | 0.010 | 0.50 | 20.5–23.0 | 26.0–28.0 | 6.5–8.0 | 0.30–0.40 |
| S31600 | 316 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0–18.0 | 10.0–14.0 | 2.00–3.00 | 0.10 |
| S31603 | 316LC | 0.030 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0–18.0 | 10.0–14.0 | 2.00–3.00 | 0.10 |
| S31700 | 317 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 18.0–20.0 | 11.0–15.0 | 3.0–4.0 | 0.10 |
| S32100 | 321 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0–19.0 | 9.0–12.0 | ||
| S34700 | 347 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0–19.0 | 9.0–13.0 | ||
| S34751 | 347LN | 0.005–0.020 | 2 | 0.045 | 0.030 | 1.00 | 17.0–19.0 | 9.0–13.0 | . . . | 0.06–0.10 |
| S40500 | 405 | 0.08 | 1 | 0.04 | 0.030 | 1.00 | 11.5–14.5 | ... | ... | |
| S40976 | ... | 0.03 | 1 | 0.04 | 0.030 | 1.00 | 10.5–11.7 | 0.75–1.00 | 0.040 | |
| S43000 | 430 | 0.12 | 1 | 0.04 | 0.030 | 1.00 | 16.0–18.0 | ... | ||
| S44400 | ... | 0.025 | 1 | 0.04 | 0.030 | 1.00 | 17.5–19.5 | 1.00 | 1.75–2.50 | 0.035 |
| S44600 | 446 | 0.2 | 1.5 | 0.04 | 0.030 | 1.00 | 23.0–27.0 | ... | 0.25 | |
| S44700 | . . . | 0.01 | 0.3 | 0.025 | 0.020 | 0.20 | 28.0–30.0 | 0.15 | 3.5–4.2 | 0.020 |
| S44800 | . . . | 0.01 | 0.3 | 0.025 | 0.020 | 0.20 | 28.0–30.0 | 2.00–2.50 | 3.5–4.2 | 0.020 |
| S44535 | . . . | 0.03 | 0.30–0.80 | 0.05 | 0.020 | 0.50 | 20.0–24.0 | . . . | . . . | . . . |
| S40300 | 403 | 0.15 | 1 | 0.04 | 0.030 | 0.50 | 11.5–13.0 | . . . | . . . | . . . |
| S41000 | 410 | 0.15 | 1 | 0.04 | 0.030 | 1.00 | 11.5–13.5 | . . . | . . . | . . . |
| S41400 | 414 | 0.15 | 1 | 0.04 | 0.030 | 1.00 | 11.5–13.5 | 1.25–2.50 | . . . | . . . |
| S42000 | 420 | over 0.15 | 1 | 0.04 | 0.030 | 1.00 | 12.0–14.0 | . . . | . . . | . . . |
| S43100 | 431 | 0.2 | 1 | 0.04 | 0.030 | 1.00 | 15.0–17.0 | 1.25–2.50 | ` | . . . |
| S44002 | 440A | 0.60–0.75 | 1 | 0.04 | 0.030 | 1.00 | 16.0–18.0 | . . . | 0.75 | . . . |
| S44003 | 440B | 0.75–0.95 | 1 | 0.04 | 0.030 | 1.00 | 16.0–18.0 | . . . | 0.75 | . . . |
| S44004 | 440C | 0.95–1.20 | 1 | 0.04 | 0.030 | 1.00 | 16.0–18.0 | . . . | 0.75 | . . . |
Terms:
1) Loading Port: Shanghai or Nantong
2) Delivery term: FOB,CFR, CIF, EXW
3) Delivery lead time: 15 working days after received deposit.
4) Payment term:30% by T/T as deposit., balance will be paid by T/T ,
5) Quality assurance: Mill Test Certificate is supplied with shipment, third Party Inspection is acceptable
Product Application:
Our range of cold forging stainless steels & rods are used to manufacture automotive products, balls & taper roller bearings, braiding hoses, chains, conveyor belts, filters, free cutting wires, fasteners and wire nails, flexible connectors, kitchen ware and gadgets, mig & tig welding, needles, pins, sieves, spokes, springs, surgical equipments, scrubber / scouring pads, steel wool, utensils, woven & knitted wire cloth, wall ties & tying wire, wire ropes, welding electrodes and fillers etc. Annealed wires are also used for redrawing.
Our advantage:
Our wire rod division is well equipped with a fully automatic wire rod mill and solution annealing, soft annealing & pickling plants with high end automation facilities, and proven quality standards.
Our wires division is well-equipped for producing high quality products having in-house facilities for solution annealing, bright annealing (continuous strand annealing), dry and wet wire drawing, high speed drawing, medium wire pattern laying, fine wire spooling, layer winding, random winding, TIG wire straightening, and cutting facilities.
