1J66 Thickness 0.05—0.1mm Width 10—200mm Hv 240--280
Description:
In a relatively wide range of magnetic Poor, certain wide temperature and frequency range, the magnetic permeability is substantially constant.
Applications:
Constant inductance coil and filter choke core, the wideband transformer core and medium-power unipolar pulse transformer core.
Specifications:
Thickness:0.05—0.10mm
Width:10—200mm
Tolerance: +/-0.01mm.
Other specifications can be customized
Surface:2B
Hardness:240—280HV(As order’s requirements)
MOQ:1 tons
Port of Loading:Shanghai
Payment:T/T
Chemical Conposition:
|
Alloy Name |
C |
P |
S |
Si |
Mn |
Ni |
Fe |
|
≤ |
|||||||
|
1J66 |
0.03 |
0.020 |
0.020 |
0.10 |
0.7—1.10 |
64.5—65.5 |
Rest |
Magnetic properties:
|
Alloy Name |
Thickness/mm |
Level |
Induction magnetic permeability μL(mH/m) ≤ |
AC stable value α~%
|
Stable value of the AC and DC α~% |
Temperature stable value αT% |
|
≤ |
||||||
|
1J66 |
0.05—0.10mm |
| |
2800(3.50) |
10 |
9 |
8 |
|
|| |
3000(3.75) |
7 |
6 |
5 |
||
Competitive Advantage:
First-class quality, complete specifications, reasonable price, timely delivery and rigorous specified according to customer requirements, suited materials for basic principles, to allow customers to buy satisfaction with assured.
