| Place of Origin: | CHINA |
|---|---|
| Brand Name: | STTOY |
| Model Number: | Alloy cold rolled steel strip |
| Minimum Order Quantity: | 1 ton |
| Packaging Details: | Pallet(required by the customers' requirements) |
| Delivery Time: | 20-60 working day |
| Payment Terms: | L/C,T/T,Paypal |
| Supply Ability: | 100 tons |
| High Light: | galvanised steel strip,cold rolled coil |
||
|---|---|---|---|
Description:
Having a high saturation magnetic induction, high saturation induced magnetic telescopic, a higher Curie temperature and a high mechanical strength.
Applications:
Normal and superconducting magnets, electromagnets, small power transformers, chokes, magnetic magnifying glass core, magnetic shielding, of aviation motor and generator rotor and stator, telephone vibration piece, magnetostrictive transducers, ultrasonic generatorvibrator, aviation and power transformers, the print head.
Specifications:
Thickness:0.05—1.00mm Width:60—200mm
Tolerance: +/-0.01mm.
Other specifications can be customized
Surface:2B
Hardness:240—280HV(As order’s requirements)
MOQ:1 tons
Port of Loading:Shanghai
Payment:T/T
Chemical composition:
|
Alloy name |
C |
P |
S |
Mn |
Si |
Ni |
CU |
Co |
V |
Fe |
|
<= |
||||||||||
|
1J22 |
0.04 |
0.020 |
0.020 |
0.30 |
0.30 |
0.50 |
0.20 |
49.0-51.0 |
0.80-1.80 |
rest |
Physical properties:
|
Alloy name |
Product name |
A/m , /T |
Hc |
|||||
|
B400 |
B800 |
B1600 |
B2400 |
B4000 |
B8000 |
/A*m-1 |
||
|
>= |
<= |
|||||||
|
1J22 |
Cold rolled steel strip |
1.6 |
1.8 |
2.0 |
2.1 |
2.15 |
2.2 |
128 |
|
- |
- |
- |
2.05 |
2.15 |
2.2 |
144 |
||
Competitive Advantage:
First-class quality, complete specifications, reasonable price, timely delivery and rigorous specified according to customer requirements, suited materials for basic principles, to allow customers to buy satisfaction with assured.
